Product Availabilities

Available Specification

T1, T2, T3, T4, T5
Specification Sheets Coil
Thickness (mm) 0.15 - 060 0.15 - 0.60
Width (mm) 650 - 988 650 - 988
Length (mm) 457 - 1200
Inside Diameter (mm)   406,508
Outside Diameter (mm)   1725
Weight (mtons) Max. 2 3 - 11

DR8, DR9, DR10
Specification Sheets Coil
Thickness (mm) 0.14 - 0.36 0.14 - 0.36
Width (mm) 650 - 988 650 - 988
Length (mm) 457 - 1200
Inside Diameter (mm)   406,508
Outside Diameter (mm)   1725
Weight (mtons) Max. 2 3 - 11
Note:
Certain combination of specification is subject to further verification
For primary scroll , please contact us



Coating Weight

Equal Coated
Letter Symbol of Classification SPTE
Designation of Coating Weight (g/m2) 2.8 / 2.8
5.6 /5.6
8.4 /8.4
11.2 /11.2
Nominal Coating Weight (g/m2) 2.8 / 2.8
5.6 /5.6
8.4 /8.4
11.2 /11.2
Minimum Average Coating Weight (g/m2) 4.9
10.5
15.7
20.2
Coating Number (reference only) #25
#50
#75
#100

Differential Coated
Letter Symbol of Classification SPTE
Designation of Coating Weight (g/m2) 2.8 / 5.6
2.8 / 8.4
2.8 / 11.2
5.6 / 8.4
5.6 / 11.2
8.4 / 11.2
Nominal Coating Weight (g/m2) 2.8 / 5.6
2.8 / 8.4
2.8 / 11.2
5.6 / 8.4
5.6 / 11.2
8.4 / 11.2
Minimum Average Coating Weight (g/m2) 2.25 / 5.05
2.25 / 7.85
2.25 / 10.1
5.05 / 7.85
5.05 / 10.1
5.05 / 10.1
Coating Number (reference only) #25 / 50
#25 / 75
#25 / 100
#50 / 75
#50 / 100
#75 / 100
Note:
Coating weight in g/m2 corresponds to JIS G 3303 - 2017
Value with slash (/) shows the coating weight on each respective surface,; values without slash (/) show the actual coating weight on both surfaces.
For coating weight not listed in table, please contact us

Differentially Coated
Designation of Coating Weight (g/m2) #25 / 50 (2.8 / 5.6)
#25 / 75 (2.8 / 8.4)
#25 / 100 (2.8 / 11.2)
#50 / 75 (5.6 / 8.4)
#50 / 100 (5.6 / 11.2)
Parallel Lines on Heavier Side Line intervals of either 2" or 4"
Edge Lines on Lighter Side A line is marked within 10 mm from an edge.

Examples of Markings
Designation of Coating Weight (g/m2)
Parallel Lines on Heavier Side

Rolling Direction
Edge Lines on Lighter Side

Rolling Direction
Note:
If different marking is required, please contact us

Temper

Single-Reduce Tinplate

T - 1
Aimed
Rockwell
Hardness
Range
30T
46 - 52
Charac-
terisic
Soft for drawing
Application Nozzles, spouts, toys and other applications requiring extra deep drawing

T - 2
Aimed
Rockwell
Hardness
Range
30T
50 - 56
Charac-
terisic
Moderate drawing where some stiffness is required
Application Rings and plugs, small-deformed cans, and other applications requiring moderately-deep drawing

T - 2.5
Aimed
Rockwell
Hardness
Range
30T
52 - 58
Charac-
terisic
Combines the characteristics of T - 2 and T - 3
Application Battery cells bodies, small can ends and bodies, and other applications requiring moderately-deep drawing

T - 3
Aimed
Rockwell
Hardness
Range
30T
54 - 60
Charac-
terisic
Shallow drawing, general purpose with fair degree of stiffness to minimize fluting
Application Can ends and bodies, large diameter closures, crown caps

T - 4
Aimed
Rockwell
Hardness
Range
30T
58 - 64
Charac-
terisic
Moderate stiffness
Application Can ends and bodies where comparatively high strength is required

T - 5
Aimed
Rockwell
Hardness
Range
30T
62 - 68
Charac-
terisic
Increased stiffness to resist buckling
Application Can ends and bodies where a combination of high hardness, strength and good formability is required


Double - Reduce Tinplate

DR - 8
Aimed Rockwell
Hardness Range 30T
Application
68 - 78 Bodies and ends for small diameter cans requiring high strength

DR - 9
Aimed Rockwell
Hardness Range 30T
Application
71 - 81 Bodies and ends for small diameter cans requiring high strength

DR - 10
Aimed Rockwell
Hardness Range 30T
Application
75 - 85 Bodies and ends for small diameter cans requiring high strength
DR tinplate is thin, strong material developed as a substitute for ordinary tinplate to meet customer's requirements to reduce tinplate thickness

Features
Stifness and strength are greater for same thickness of ordinary tinplate
Reduced thickness make it possible to increase the number of sheets per unit mass, and consequently reduce costs

Finishes

Code /
Classification
Features
B /
Bright
A luster surface provided by a flow-brightened tin coating on a smooth grindstone finish steel base
R /
Stone
Melted finish. This finish has fine grit lines, and is easy to handle because it resists scratching during coating and can-making
R2 /
Super
Stone
Melted finish. High resistance to scratching, thus making it easy to handle during coating and can-making and is widely used for cna ends
M /
Matte
Unmelted dull finish. This finish gives the tinplate a unique silver gray surface. It offers exceptional ink adherence and is widely used in crown caps and printed cans
S /
Silver
A luster surface provided by a flow-brightened tin coating on a coarse dull finished steel base
Note: Double reduced product is available in stone and super stone finish only



Steel Type

Steel Types Remarks
MR Contains low residual elements and has good corrosion resistance. Commonly used for most tinplate applications
L Contains particularly low residual elements such as Cu, Ni, Cr and Mo and is used for improved corrosion resistance of certain food-product containers
D Aluminium killed, is sometimes required for severe drawing applications or to minimize severe fluting and stretcher strain hazards
