Product Availabilities

Available Specification

Specification T1, T2, T3, T4, T5 DR8, DR9, DR10
Sheets Coil Sheets Coil
Thickness (mm) 0.15 - 060 0.15 - 0.60 0.14 - 0.36 0.14 - 0.36
Width (mm) 650 - 965 650 - 965 650 - 982 650 - 982
Length (mm) 457 - 1200   457 - 1200
Inside Diameter (mm)   406, 419, 508   406, 419, 508
Outside Diameter (mm)   1725   1725
Weight (mtons) Max. 2 3 - 11 Max. 2 3 - 11
Note:
  • Certain combination of specification is subject to further verification.
  • For primary scroll, please contact us.
Tin Free Steel   Tin Free Steel


Coating Weight

Letter Symbol of Classification Type of Coating Designation of Coating Weight (g/m2) Nominal Coating Weight (g/m2) Minimum Average Coating Weight Coating Number (reference only)
SPTE Equal Coated
  • 2.8 / 2.8
  • 5.6 / 5.6
  • 8.4 / 8.4
  • 11.2 / 11.2
  • 2.8 / 2.8
  • 5.6 / 5.6
  • 8.4 / 8.4
  • 11.2 / 11.2
  • 4.9
  • 10.5
  • 15.7
  • 20.2
  • #25
  • #50
  • #75
  • #100
Differential Coated
  • 2.8 / 5.6
  • 2.8 / 8.4
  • 2.8 / 11.2
  • 5.6 / 8.4
  • 5.6 / 11.2
  • 8.4 / 11.2
  • 2.8 / 5.6
  • 2.8 / 8.4
  • 2.8 / 11.2
  • 5.6 / 8.4
  • 5.6 / 11.2
  • 8.4 / 11.2
  • 2.25 / 5.05
  • 2.25 / 7.85
  • 2.25 / 10.1
  • 5.05 / 7.85
  • 5.05 / 10.1
  • 5.05 / 10.1
  • #25 / 50
  • #25 / 75
  • #25 / 100
  • #50 / 75
  • #50 / 100
  • #75 / 100
Note:
  • Coating weight in g/m2 corresponds to JIS G 3303 - 2017.
  • Value with slash (/) shows the coating weight on each respective surface,; values without slash (/) show the actual coating weight on both surfaces.
  • For coating weight not listed in table, please contact us.


Coating Mass (TFS):

Designation of Coating Weight Nominal Coating Weight (one side) Minimum Average Coating Weight (one side)
(mg/m2) (g/m2)
# 80/80 80 50
# 100/100 100 50
# 110/110 110 50
# 120/120 120 120


Designation and Marking for Differential Coating

Type Designation of Coating Weight (g/m2) Differential Marking
Parallel Lines on Heavier Side Edge Lines on Lighter Side
Differentially Coated
  • #25 / 50 (2.8 / 5.6)
  • #25 / 75 (2.8 / 8.4)
  • #25 / 100 (2.8 / 11.2)
  • #50 / 75 (5.6 / 8.4)
  • #50 / 100 (5.6 / 11.2)
Line intervals of either 2" or 4" A line is marked within 10 mm from an edge.
Examples of Markings   Rolling Direction

Rolling Direction
Rolling Direction

Rolling Direction
Note:
  • If different marking is required, please contact us.


Temper

Single - Reduce Tinplate

Designation Aimed Rockwell Hardness Range 30T Characteristic Application
T - 1 46 - 52 Soft for drawing Nozzles, spouts, toys, and other applications requiring extra deep drawing
T - 2 50 - 56 Moderate drawing where some stiffness is required Rings and plugs, small-deformed cans, and other applications requiring moderately-deep drawing
T - 2.5 52 - 58 Combines the characteristics of T - 2 and T - 3 Battery cells bodies, small can ends, and bodies, and other applications requiring moderately-deep drawing
T - 3 54 - 60 Shallow drawing, general purpose with fair degree of stiffness to minimize fluting Can ends and bodies, large diameter closures, crown caps
T - 4 58 - 64 Moderate stiffness Can ends and bodies where comparatively high strength is required
T - 5 62 - 68 Increased stiffness to resist buckling Can ends and bodies where a combination of high hardness, strength, and good formability is required


Single - Reduce Tinplate

Designation Aimed Rockwell Hardness Range 30T Application
DR - 8 68 - 78 Bodies and ends for small diameter cans requiring high strength
DR - 9 71 - 81 Bodies and ends for small diameter cans requiring high strength
DR - 10 75 - 85 Bodies and ends for small diameter cans requiring high strength
DR tinplate is thin, strong material developed as a substitute for ordinary tinplate to meet customer's requirements to reduce tinplate thickness
Note:
  • Stiffness and strength are greater for same thickness of ordinary tinplate
  • Reduced thickness make it possible to increase the number of sheets per unit mass, and consequently reduce costs


Finishes

Code Classification Features
B Bright A luster surface provided by a flow-brightened tin coating on a smooth grindstone finish steel base
R Stone Melted finish. This finish has fine grit lines and is easy to handle because it resists scratching during coating and can-making
R2 Super Stone Melted finish. High resistance to scratching, thus making it easy to handle during coating and can-making and is widely used for cna ends
M Matte Unmelted dull finish. This finish gives the tinplate a unique silver gray surface. It offers exceptional ink adherence and is widely used in crown caps and printed cans
S Silver A luster surface provided by a flow-brightened tin coating on a coarse dull finished steel base
Note:
  • Double reduced product is available in stone and super stone finish only.
Finishes   Finishes   Finishes


Steel Types

Steel Types Remarks
MR Contains low residual elements and has good corrosion resistance. Commonly used for most tinplate applications
L Contains particularly low residual elements such as Cu, Ni, Cr, and Mo and is used for improved corrosion resistance of certain food-product containers
D Aluminium killed, is sometimes required for severe drawing applications or to minimize severe fluting and stretcher strain hazards
